Product Information

Your ultimate tone control rig.
Ready to rock. Ready to record.

The ultimate floor tone rig

iRig Stomp I/O is a brand new type of USB pedalboard controller that integrates a professional, high-resolution, MFi certified audio interface with MIDI input/output for iPhone, iPad, Mac, and PC. It comes bundled with state-of-the-art guitar, vocal processing, and recording software for flexibility and usability, both live and in the studio.

iRig Stomp I/O








Sturdy and robust, yet easily transportable, iRig Stomp I/O features four onboard metal stomp switches plus an expression pedal with a switch, all with LED indicators. To further extend its control possibilities, you can connect up to 2 additional switches or pedals. The MIDI IN/OUT ports make it possible to seamlessly control external processors when iRig Stomp I/O is used as a stand-alone MIDI foot controller, without any device or computer connected to it.

iRig Stomp I/O

The Neutrik® 1/4" XLR combo jack accepts instruments and microphones including condenser mics with switchable 48V phantom power. The balanced stereo output connects to an external amp, mixer or PA, and a 1/4" stereo headphone output is available for silent monitoring. The input gain and volume output knobs are easily accessible on the front panel, each with its dedicated LED VU-Meter indicator, for the quick-and-easy setting of levels.

iRig Stomp I/O also takes the concept of versatility to a whole new level, by combining a smart, hi-tech hardware system with an incredible collection of complete, professional software and apps worth over $/€800.



iRig Stomp I/O



iRig Stomp I/O



iRig Stomp I/O





Ready to rock, ready to record

iRig Stomp I/O boasts an elegant all-in-one design that perfectly highlights its flexibility and versatility. In a single piece of equipment, you now have everything you need to record in the studio, rehearse, or go out on stage and gig, without having to assemble a bulky and costly hardware setup.

With its high-quality 96kHz/24-bit audio interface, iRig Stomp I/O lets you easily record your guitar, bass or microphone - including studio condensers requiring 48VDC phantom power with true studio quality on iPhone/iPad, Mac and PC. The seamless integration with AmpliTube and VocaLive makes it as easy as plug-and-play to record on multiple devices using IK’s powerful, state of the art, 64-bit software. iRig Stomp I/O features a Class A preamp that can rival, if not surpass, the sound quality of floor processors costing up to three times as much.

iRig Stomp I/O

The integrated headphone output allows you to monitor the signal during tracking or when practicing, while the balanced stereo outputs can be used to send the signal to an amplifier, a mixer, a PA or powered speakers.

iRig Stomp I/O

As a floor controller, iRig Stomp I/O features an onboard expression pedal and four foot switches, allowing you to seamlessly flip through your favorite presets for natural, hands-free performance. The two optional control inputs let you connect up to two additional external pedals/switches. To further extend your control possibilities, you can exploit its MIDI functionality to send MIDI control messages via its MIDI OUT to your external gear and processors, using iRig Stomp I/O as a MIDI interface or as a stand-alone controller (even without a device).



Ideal for guitar, bass, vocals and synths

iRig Stomp I/O is designed to give guitarists, both electric and acoustic, bass players, vocalists, and songwriters a new way to have full control over their tone, in any situation.

iRig Stomp I/O

Its versatility works wonders even on hardware synthesizers, for sonic combinations never heard before.



iRig Stomp I/O

Seamless software integration

iRig Stomp I/O is designed to seamlessly integrate with AmpliTube for Mac/PC and iOS as well as with VocaLive for iOS, for full-blown performance in the studio and live.

While using AmpliTube or VocaLive with iPhone, iPad, Mac, PC and PC tablets like Microsoft® Surface, you can easily browse your tone presets, preset banks, control wah processors in real time using the integrated expression pedal, as well as quickly access useful functions like the Looper, the Tuner, and more.

iRig Stomp I/O gives you the unique advantage to have the very same sound on stage as in the studio, with full preset portability.

iRig Stomp I/O



Work out of the box

Bundled with over $/€800 worth of professional software, iRig Stomp I/O encompasses the right tools for all kinds of musical needs.

It puts all the power of AmpliTube 4 Deluxe – the world’s best sounding guitar amp and FX modeling and vocal processing software right at your feet, with a collection of over 160 gear models for Mac/PC and 70 for iOS.

iRig Stomp I/O

Electric guitarists and bass players can also unleash the full power of AmpliTube for iPhone and iPad, while acoustic guitarists can shape their tone with AmpliTube Acoustic for iOS and singers can experiment with VocaLive and give their vocals some mojo with Mic Room. Plus, anybody can post-process their recordings using four select processors from IK’s flagship T-RackS 5 mixing and mastering suite (the White 2ABlack 76and VC-670 compressors, the EQP-1A equalizer and Mic Room), for authentic analog studio sound.

iRig Stomp I/O

Unlike most floor controllers which are self-contained, closed systems, iRig Stomp I/O is also easily updatable as new software and features are released, making it a future-proof system that easily competes with high-end pedalboards.



With your device or stand-alone

A unique advantage of iRig Stomp I/O is its plug-and-play ease of use. As an MFi certified audio interface, it is designed to work right out of the box with your iPhone and iPad using the included lightning cable as well as with Mac and PC via USB.



iRig Stomp I/O



iRig Stomp I/O



iRig Stomp I/O



iRig Stomp I/O





iRig Stomp I/O

It is the only floor controller to feature a convenient device bay, where you can safely position your iOS device – charging it during use - for an immediate and clear view of the interface. Used with PC tablets like Microsoft® Surface, you can take advantage of the touchscreen interface for enhanced speed and flexibility in creating and tweaking your tones.

iRig Stomp I/O can be used without a device as a stand-alone MIDI foot controller that can be integrated with regular hardware rigs and used to control outboard processors that accept MIDI patch change and continuous controls.



iRig Stomp I/O

Built-like a tank, road-ready

iRig Stomp I/O is built to last, boasts an elegant design, features a sturdy metal chassis and has no fear of the road since it is compact and easily transportable. Like most IK Multimedia products, it is made in IK's Modena factory and offers the renowned quality and craftsmanship of products made in Italy.

If you want to hit the road in style, there is a sleek iRig Stomp I/O travel bag available.



At a glance

  • Four onboard switches, expression pedal with optical switch
  • 96kHz/24-bit built-in high-quality audio interface with input gain and volume control
  • Hi-Z/Mic/Line Neutrik® combo input, balanced stereo, and headphone output
  • Class A preamp with +48V phantom power for condenser microphones
  • In/out LED bar VU-Meters
  • MIDI in/out with two additional 1/4" switch/pedal controller inputs
  • Integrated device bay for easy positioning of iPhone, iPad or Microsoft Surface
  • Over $/€800 of included software and apps: AmpliTube 4 Deluxe, T-RackS processors (White 2ABlack 76VC-670EQP-1AMic Room) and Ableton® Live 9 Lite™ for Mac/PC, AmpliTube and AmpliTube Acousticfor iOS, VocaLive iOS and Mic Room for iOS
  • Seamless, plug and play integration with AmpliTube (iOS/Mac/PC) and VocaLive (iOS)
  • When used with iPhone and iPad it charges your device while you play
  • Can also work as a standalone MIDI foot controller, without a device or computer
  • Road-ready, rugged metal construction - can be carried anywhere
  • Ideal for both studio and live use
  • Optimal for guitar and bass players, singers, and vocalists
  • Includes Mini-DIN/Lightning and USB cable
  • Powered via USB or DC Adaptor
  • Designed and made in Italy

Specs

iRig Stomp I/O Specifications

Common

  • Conversion: 24-bit A/D, 24-bit D/A
  • Sampling Rate: 44.1 kHz, 48 kHz, 88.2 kHz and 96 kHz
  • Power: USB bus powered (when used with a computer) or DC IN
  • Device Connection: USB B-Type and Mini-DIN
  • Enclosure: metal sheet

Microphone Input

  • Connector: balanced female 3-pin XLR. Pin 2: hot / Pin 3: cold / Pin 1: ground
  • Microphone Input Level: from 6 mVpp to 1.4 Vpp
  • Microphone Input Impedance: 3.2 kOhms
  • Gain Range: 46 dB
  • Phantom Power: +48V ± 4V
  • Frequency Response: 20 Hz – 20kHz +/-1.5dB
  • Input Noise: -100 dB RMS

Instrument Input

  • Connector: unbalanced, Hi-Z, TS 1/4" Jack. Tip: signal / Shield: ground
  • Instrument Input Level: from 30mVpp to 6.9Vpp
  • Instrument Input Impedance: 1MOhms
  • Gain Range: approx 27dB
  • Frequency response: 20 Hz – 20kHz +/-1.5dB
  • Input Noise: -100 dB RMS

Stereo Headphone Output

  • Connector: 1/4" TRS Jack. Tip: right / Ring: left / Shield: ground
  • Headphone Level control: potentiometer
  • Headphone Output Power: 100mW into 50Ohms

Stereo Line Output

  • Connector: 2x balanced female 1/4" TRS Jack. Tip: hot / Ring: cold / Shield: ground
  • Maximum Output Level: +13 dBu into 600 Ohms balanced load
  • Frequency Response: from 10 Hz to 21 kHz (+/- 0.2dB)
  • Output Dynamic Range: 102 dB(A)
  • Output Impedance: 150 Ohms balanced
  • Floating Balanced Outputs

MIDI Input/Output

  • Connector: 2x 5-pin DIN

Connections and Controls

Top Panel

  • Four metal foot-switches with one indication LED each, dual color
  • Two analog potentiometers for Input GAIN and output VOLUME
  • "Stomp MODE" LED
  • "Phantom 48V" LED
  • "PEDAL" LED
  • 4 segments mono input level meter (peak)
  • 4 segments device output meter (peak)
  • Continuous pedal (expression pedal) with virtual switch at the top of its travel

Rear Panel

  • Neutrik Combo socket for MIC input and Instrument input (auto selecting)
  • +48V phantom power switch
  • 1/4" headphones output
  • 2 x 1/4" TRS Balanced floating line outputs
  • MIDI I/O 5-pin DIN connectors
  • 2 x 1/4" TRS External controllers sockets
  • B-Type USB socket for connecting a computer (Mac/PC)
  • Mini-DIN "iOS" connector for connecting an iOS device
  • Barrel DC-in socket for powering up the Stomp I/O and charging the iOS device at the same time

Package includes

  • iRig Stomp I/O
  • Lightning to Mini-DIN connection cable (60cm/23.62")
  • USB A-Type to USB B-Type connection cable (2.5m/8.2ft)
  • DC power supply

Dimensions

  • Size: 41.5cm/16.3" x 21cm/8.5" x 7.2cm/2.83"
  • Weight: 3.2kg/7.1lb
  • Lightning to Mini-DIN connection cable (60cm/23.62")
  • USB A-Type to USB B-Type connection cable (2.5m/8.2ft)

Compatibility

iOS Devices

Compatible with iPhone 8 Plus, iPhone 8, iPhone SE, iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 6, iPhone 5s, iPhone 5c, iPhone 5, iPod touch 6th generation, iPod touch 5th generation, iPad Pro (10.5-inch), iPad Pro (12.9-inch) 2nd generation, iPad Pro (12.9-inch) 1st generation, iPad Pro (9.7-inch), iPad mini 4, iPad Air 2, iPad mini 3, iPad Air, iPad mini 2, iPad mini, iPad 5th generation, iPad 4th generation. iOS 6 or later is required.



Computers

Mac®: Mac OS X 10.6 or later. One free USB port.

Windows®: Fully supports Windows 10 WASAPI for low latency audio. One free USB port.
(ASIO4ALL is required on Windows 7 and 8 for low latency audio. See our FAQ here for further details.)
